Launch Limiter

This page is dedicated to the 10RSTAGER, which builds upon True Motorsport’s existing Smooth Stage technology. The 6RSTAGER has been adapted to control the Ford 10R80 Transmission in order to effectively stage at the drag strip.


Way too often we try and create solutions by thinking outside the box, when sometimes the best solution is… inside the box. With a simple and logical approach, the Launch Limiter was created with an innovative analog electronic design that resides… inside of a box.

What is the Launch Limiter? In simple terms, you can think of it as a Rev Limiter for your Foot Pedal signal.

How does it limit the Pedal Signal? We use analog design circuitry, that compares the input pedal signal level to the desired user selected setting. When the Launch Limiter is enabled, the pedal signal sent to the Power Control Module (PCM) is restricted to one of 12 settings. Simplicity in this design is key feature of this product as it doesn’t rely upon an overly complicated microcontroller or microprocessor based system. It’s a simple, logic level design, in which you don’t have to worry about software bugs that give you undesired results.

When lining up at the drag strip, getting your drive train and suspension loaded up while holding your target RPM is essential for maximizing your 60ft times. The Launch Limiter takes a straightforward method for loading up your drive train by placing a maximum signal level threshold to the pedal position signal that is sent from your pedal to the PCM. With the Launch Limiter activated, a 0% pedal position is read by the PCM as 0% pedal position and when at 100% pedal position, your PCM may only think that your pedal position is at 25%. In this example, any pedal position lower than 25% will read the actual value. To adjust this maximum pedal position value, simply turn the knob on the Launch Limiter up or down based upon your desired engine load.

How do you use the Launch Limiter? To use the Launch Limiter, first apply your foot onto the foot brake, and place your vehicle into your desired launch gear. Simply hold the Launch Limiter button down while increasing the pedal position. If holding the pedal in a WOT position, the PCM will only see the maximum pedal position setting that is provided by the Launch Limiter. As soon as the button is released, the “real” pedal position value is sent to the PCM.

Using this approach at the drag strip allows you to get into the staging beams, dial in a desired launch RPM while loading up your suspension. As soon as the light goes green, release the foot brake and the Launch Limiter button for your commanded WOT signal to take over and be passed along to the PCM.


THE LAUNCH LIMITER Will work on MOST FORD and CHRYSLER DRIVE BY WIRE APPLICATIONS!

using our plug and play wire harness, installation is simple to use.



FEATURES:

  • LED Indication of Activation

  • 12 Pedal Limit settings with an easy to use knob

  • Plug and Play harness for easy to use installation

  • Works on Ford drive by wire applications

  • Work on most Dodge/Chrysler drive by wire vehicles

  • Can be used to easily incorporate a valet mode using a switch

  • Includes the new Ford Brake Pedal Position Breakout Harness (not available for Dodge)

Launch Limiter
$325.00

Plug and Play Launch Limiter for drive by wire for most Ford and Chryslers.

Purchase includes: Launch Limiter Control Box, Plug and Play Accelerator Harness, Ford Brake Pedal Breakout Harness, optional relay and handheld push button switch
